  • 300 Series 2-1/2 in. Gauge Size Brass Case Liquid Filled Pressure Gauge (25-300-SST-1000-psi)
  • High quality, heavy-duty liquid filled gauge
  • Vacuum and compound ranges through 0 psi to 15,000 psi
  • Die cast Brass case with natural Brass finish
  • Copper alloy or 316 Stainless Steel and Brass wetted parts
  • Cleaning for Oxygen Service (O2) is available only for dry or HL (Halocarbon) filled gauges
  • For gauges with MIP, GY40 fill is standard for liquid filled gauges
1 - 25 of 804 | Results Per Page | View | Unit of Measure
1 2 3 4 5 »
Request Information Compare Items
Clear Filter

Gauge Size (in)

  • No Preference
  • 2-1/2
  • 4

Connection Size

Connection Location

  • No Preference
  • Back
  • Bottom

Pressure Range

Scale Option

Case Material

  • No Preference
  • Die Cast Brass (Natural Brass Finish) with Safety Relief Plug

Measuring Element

Stock

  • No Preference
  • Yes

Part Number

Description

Full Scale Best Fit Straight Line (BFSL) Accuracy (±)

Gauge Size

Pressure Range

Media Temperature Range

25-300-10000-psi N/A 2-1/2" Brass Case, Copper Alloy Internals, 10,000 psi, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled N/A 1.6 % N/A 2-1/2 in N/A 0 to 10,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-10000-psi/bar N/A 2-1/2" Brass Case, Copper Alloy Internals, 10,000 psi/bar, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled N/A 1.6 % N/A 2-1/2 in N/A 0 to 10,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-10000-psi/kg/cm2 N/A 2-1/2" Brass Case, Copper Alloy Internals, 10,000 psi/kg/cm², 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled N/A 1.6 % N/A 2-1/2 in N/A 0 to 10,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-10000-psi/kPa N/A 2-1/2" Brass Case, Copper Alloy Internals, 10,000 psi/kPa, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled N/A 1.6 % N/A 2-1/2 in N/A 0 to 10,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-10000-psi-BFF N/A 2-1/2" Brass Case, Copper Alloy Internals, 10,000 psi, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled and Brass Front Flange N/A 1.6 % N/A 2-1/2 in N/A 0 to 10,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-10000-psi-BT8 N/A 2-1/2" Brass Case, Copper Alloy Internals, 10,000 psi, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled and 0.8 mm Brass Threaded Orifice N/A 1.6 % N/A 2-1/2 in N/A 0 to 10,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-10000-psi-MIP N/A 2-1/2" Brass Case, Copper Alloy Internals, 10,000 psi, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled and Maximum Indicating Pointer N/A 1.6 % N/A 2-1/2 in N/A 0 to 10,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-1000-psi N/A 2-1/2" Brass Case, Copper Alloy Internals, 1,000 psi, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled N/A 1.6 % N/A 2-1/2 in N/A 0 to 1,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-1000-psi/bar N/A 2-1/2" Brass Case, Copper Alloy Internals, 1,000 psi/bar, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled N/A 1.6 % N/A 2-1/2 in N/A 0 to 1,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-1000-psi/bar-BT8 N/A 2-1/2" Brass Case, Copper Alloy Internals, 1,000 psi/bar, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled and 0.8 mm Brass Threaded Orifice N/A 1.6 % N/A 2-1/2 in N/A 0 to 1,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-1000-psi/kg/cm2 N/A 2-1/2" Brass Case, Copper Alloy Internals, 1,000 psi/kg/cm², 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled N/A 1.6 % N/A 2-1/2 in N/A 0 to 1,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-1000-psi/kPa N/A 2-1/2" Brass Case, Copper Alloy Internals, 1,000 psi/kPa, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled N/A 1.6 % N/A 2-1/2 in N/A 0 to 1,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-1000-psi-BT8 N/A 2-1/2" Brass Case, Copper Alloy Internals, 1,000 psi, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled and 0.8 mm Brass Threaded Orifice N/A 1.6 % N/A 2-1/2 in N/A 0 to 1,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-1000-psi-MIP N/A 2-1/2" Brass Case, Copper Alloy Internals, 1,000 psi, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled and Maximum Indicating Pointer N/A 1.6 % N/A 2-1/2 in N/A 0 to 1,000 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-100-psi N/A 2-1/2" Brass Case, Copper Alloy Internals, 100 psi, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled N/A 1.6 % N/A 2-1/2 in N/A 0 to 100 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-100-psi/bar N/A 2-1/2" Brass Case, Copper Alloy Internals, 100 psi/bar, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled N/A 1.6 % N/A 2-1/2 in N/A 0 to 100 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-100-psi/bar-BT8 N/A 2-1/2" Brass Case, Copper Alloy Internals, 100 psi/bar, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled and 0.8 mm Brass Threaded Orifice N/A 1.6 % N/A 2-1/2 in N/A 0 to 100 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-100-psi/kg/cm2 N/A 2-1/2" Brass Case, Copper Alloy Internals, 100 psi/kg/cm², 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled N/A 1.6 % N/A 2-1/2 in N/A 0 to 100 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-100-psi/kPa N/A 2-1/2" Brass Case, Copper Alloy Internals, 100 psi/kPa, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled N/A 1.6 % N/A 2-1/2 in N/A 0 to 100 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-100-psi/kPa-GY40-BT8 N/A 2-1/2" Brass Case, Copper Alloy Internals, 100 psi/kPa, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with -40 Degree Service Filled and 0.8 mm Brass Threaded Orifice N/A 1.6 % N/A 2-1/2 in N/A 0 to 100 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-100-psi-BT8 N/A 2-1/2" Brass Case, Copper Alloy Internals, 100 psi, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled and 0.8 mm Brass Threaded Orifice N/A 1.6 % N/A 2-1/2 in N/A 0 to 100 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-100-psi-BT8-GY40 N/A 2-1/2" Brass Case, Copper Alloy Internals, 100 psi, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with 0.8 mm Brass Threaded Orifice and -40 Degree Service Filled N/A 1.6 % N/A 2-1/2 in N/A 0 to 100 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-100-psi-DRY N/A 2-1/2" Brass Case, Copper Alloy Internals, 100 psi, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Dry Gauge N/A 1.6 % N/A 2-1/2 in N/A 0 to 100 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-100-psi-GLO N/A 2-1/2" Brass Case, Copper Alloy Internals, 100 psi, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled and Glass Lens Overlay N/A 1.6 % N/A 2-1/2 in N/A 0 to 100 psi N/A -4 to 140 ºF-20 to 60 ºC
25-300-100-psi-MIP N/A 2-1/2" Brass Case, Copper Alloy Internals, 100 psi, 1/4" National Pipe Thread (NPT) Male Bottom Connection Pressure Gauge with Glycerin Filled and Maximum Indicating Pointer N/A 1.6 % N/A 2-1/2 in N/A 0 to 100 psi N/A -4 to 140 ºF-20 to 60 ºC
