These compressed air dryers are intended for instrumentation, laboratory applications and other low-flow uses that require extremely dry or oil-free air
Removes contaminants in vapor form, which cannot be removed by filtration
The type of application should be specified as to whether dew point reduction (water vapor) or the removal of oil vapor is required

1 - 6 of 6 | Results Per Page | View | Unit of Measure

1

Request Information Compare Items

Clear Filter

Drain Type

Efficiency

Pressure [Max] (psi)

Rated Flow at 100 psig (scfm)

Connection Size (in)

Housing Material

Part Number	Description	Drain Type	Pressure [Max]	Connection Size	Housing Material

1716-6-1	N/A 1716 Series 12 scfm Metl-Guard Desiccant Dryer with Solid Aluminum Housing and SG-1 Desiccant	N/A Manual Drain	N/A 150 psi	N/A 1/2 in	N/A Aluminum
1716-6-4	N/A 1716 Series 12 scfm Metl-Guard Desiccant Dryer with Solid Aluminum Housing and AC-1 Desiccant	N/A Manual Drain	N/A 150 psi	N/A 1/2 in	N/A Aluminum
1716-6-5	N/A 1716 Series 12 scfm Metl-Guard Desiccant Dryer with Solid Aluminum Housing and MS-1 Desiccant	N/A Manual Drain	N/A 150 psi	N/A 1/2 in	N/A Aluminum
1716-10-1	N/A 1716 Series 12 scfm Visi-Guard Desiccant Dryer with Aluminum/Acrylic Housing and SG-1 Desiccant	N/A Manual Drain	N/A 150 psi	N/A 1/2 in	N/A Aluminum, Acrylic
1716-10-4	N/A 1716 Series 12 scfm Visi-Guard Desiccant Dryer with Aluminum/Acrylic Housing and AC-1 Desiccant	N/A Manual Drain	N/A 150 psi	N/A 1/2 in	N/A Aluminum, Acrylic
1716-10-5	N/A 1716 Series 12 scfm Visi-Guard Desiccant Dryer with Aluminum/Acrylic Housing and MS-1 Desiccant	N/A Manual Drain	N/A 150 psi	N/A 1/2 in	N/A Aluminum, Acrylic
